| Specifications | ||||||||
| Cable model | Number of fibers | Number of casings | Number of filled ropes | Cable diameter | Cable weight | Allowable tensile force long/short Term | Allow crushing force long/short Term | Bending radius static/dynamic |
| mm | Kg/Km | N | N | mm | ||||
| GYTA53-2~6 cores | 2~6 | 1 | 4 | 9.7 | 90 | 600/1500 | 300/1000 | 10D/20D |
| GYTA53-8~12 cores | 8~12 | 2 | 3 | 9.7 | 90 | 600/1500 | 300/1000 | 10D/20D |
| GYTA53-14~18 cores | 14~18 | 3 | 2 | 9.7 | 90 | 600/1500 | 300/1000 | 10D/20D |
| GYTA53-20~24 cores | 20~24 | 4 | 1 | 9.7 | 90 | 600/1500 | 300/1000 | 10D/20D |
| GYTA53-26~30 cores | 26~30 | 5 | 0 | 9.7 | 90 | 600/1500 | 300/1000 | 10D/20D |
| GYTA53-32~36 cores | 32~36 | 6 | 0 | 10.2 | 104 | 1000/3000 | 300/1000 | 10D/20D |
| GYTA53-38~48 cores | 38~48 | 4 | 1 | 11 | 117 | 1000/3000 | 300/1000 | 10D/20D |
| Requirement for Order | ||||||||
| (1) Fiber sort: Single mode:G652D,G657A1, G657A2, Multi mode:OM1,OM2,OM3,OM4. | ||||||||
| (2) Fiber brand: YOFC, Corning, Fiberhome,Fujikura,OFS etc. | ||||||||
| (3) Jacket material: PE、LSZH ( can be required). | ||||||||
| (4) The fiber and tube color: according to stranded color, can be required. | ||||||||
| (5) Length of cable: generally is 2KM/drum, can be required. | ||||||||
| (6) Other requirement: can be negotiated. | ||||||||
|
Fiber optical Characteristic (after cable)
|
||||||||
| Fiber type | Attenuation | Bandwidth | Effective modal bandwidth |
10 Gb/s Link Length
|
||||
| Conditions | 1310/1550nm | 850/1300nm | 850/ | 850nm | 850nm | |||
| Typical | Maximum | Typical | Maximum | 1300nm | ||||
| Unit | dB/km | dB/km | dB/km | dB/km | MHz.km | MHz.km | m | |
| G652D | 0.5/0.4 | 0.6/0.5 | / | / | / | / | / | |
| G657A1 | 0.5/0.4 | 0.6/0.5 | / | / | / | / | / | |
| G657A2 | 0.4/0.3 | 0.5/0.4 | / | / | / | / | / | |
| G657B3 | 0.5/0.4 | 0.6/0.5 | / | / | / | / | / | |
| 62.5/125 | / | / | 3.5/1.0 | 3.5/1.5 | ≥160/500 | / | / | |
| 50/125/ | / | / | 3.0/1.0 | 3.5/1.5 | ≥200/500 | / | / | |
| OM1 | ||||||||
| 50/125/ | / | / | 3.0/1.0 | 3.5/1.5 | ≥500/500 | / | / | |
| OM2 | ||||||||
| OM3-150 | / | / | 3.0/1.0 | 3.5/1.5 | ≥700/500 | ≥950 | 150 | |
| OM3-300 | / | / | 2.5/0.8 | 3.0/1.0 | ≥1500/500 | ≥2000 | 300 | |
| OM4-550 | / | / | 2.5/0.8 | 3.0/1.0 | ≥3500/500 | ≥4700 | 550 | |
