Features: |
|
|
|
|
PC,UPC,APC polishing available |
|
High returen loss |
|
Low insertion loss |
|
High reliability and stablity |
|
Available foe singlemode/multimode and simplex/duplex |
|
0.9mm,2.0mm,3.0mm diameter cable available |
|
|
|
|
|
|
|
|
|
|
|
Product Parameter |
|
|
|
|
Characteristic |
SM , MM |
Connector type |
FC/SC/ST/LC/MU/MT-RJ/ESCON/E2000 |
Diameter(mm) |
0.9、2.0、3.0 |
Polishing grade |
SM UPC |
MM UPC |
SM APC |
Insertion loss |
Grade B |
≤0.15dB |
≤0.1dB |
≤0.15dB |
Grade C |
≤0.30dB |
≤0.30dB |
≤0.30dB |
Return loss |
≥55dB |
≥30dB |
≥65dB |
Interchangeability |
≤0.1dB |
Repeatability |
≤0.1dB |
Operation temperature (℃) |
﹣20°C ~ +70°C |
Storage temperature (℃) |
﹣40°C ~ +80°C |
|
|
|
|
|
|
|
|
|
|
Applications |
|
|
|
|
1. Telecommunication |
|
|
|
|
2. Computer networks |
|
|
|
|
3. CATV networks |
|
|
|
|
4. Active device termination |
|
|
|
|
|
5. Instrumentation |
|
|
|
|
